✅ Quick Release Pin Description

This Quick Release Pin provides a simple, effective solution for fast, repeatable locking in high-use environments. The core structure consists of a solid stainless steel 304 shaft, engineered for strength and resistance to corrosion. The round top head includes a central push button, allowing the two locking balls at the tip to retract when pressed.

Once inserted into a mating hole, releasing the button allows the locking balls to expand and securely hold the pin in place. This mechanism makes the product ideal for applications requiring quick, tool-free engagement and release, particularly in setups that are changed or moved frequently.

The handle top is available in various anodized colors for easy identification. Compact in design and highly durable, this pin is commonly used in jig fixtures, frame assemblies, test stations, and structural joints.

✅ Aplicativos

• Modular fixture plates and equipment

• Robotic and automation setups

• Testing and assembly stations

• Automotive jigs and quick positioning setups

• Aerospace tooling

• Stage or lighting rig systems

• Exercise equipment or foldable structures

✅ Especificações técnicas

Standard Ranges:

• Diameter: 5 mm – 16 mm

• Usable Length (L): 10 mm – 120 mm

• Tipo de cabeça: Flat round head with central push-button

• Color Options: Black, Blue, Red, Silver (custom anodized)

Available in custom lengths, diameters, or handle styles based on your application drawings.

Principais recursos

• Spring-loaded ball locking with simple push-button release

• ️ Tool-free assembly and disassembly

• Robust stainless steel 304 shaft for durability in industrial use

• Color-coded button cap for easy identification

• Custom specifications supported (OEM/ODM)

✅ Ordering

Pino de liberação rápida

When requesting a quote, please provide:

• Shaft diameter & grip length

• Required quantity

• Color of button (if any preference)

• Ring or tether option (if needed)

• Special labeling or logo requirements
